The Double-Sided USB Type C Female Test Board is a compact diagnostic tool for verifying USB‑C port connections during device repair and assembly.
Use it to check pin continuity, confirm connector seating, and isolate port faults on smartphones, tablets, laptops, and development boards. The double‑sided layout enables access to both faces of the USB‑C interface for more complete troubleshooting.
-
Connector: Standard USB Type‑C female interface compatible with common device ports.
-
Construction: Double‑sided PCB and reinforced housing for repeated insertion cycles.
-
Accessibility: Exposes both plug faces for continuity testing and visual inspection.
-
Integration: Fits into existing bench setups; works with multimeters and logic probes.
-
Use case: For technicians and hobbyists diagnosing port alignment, shorts, or broken pins.
Specifications (light): PCB size ~30 x 18 mm, color: green, material: FR‑4 board with metalized USB‑C shell.
Fit statement: Intended for repair benches and DIY diagnostics; check device port orientation before use.
