The DSO138 oscilloscope is a fully assembled kit designed for signal analysis, featuring an ARM Cortex-M3 processor and a 2.4-inch color TFT display for clear waveform visualization.
This oscilloscope suits electronics enthusiasts and students for tasks like testing circuits, capturing transient signals, or prototyping projects. For instance, it helps in debugging by displaying frequency, period, and other parameters in real time, making it easier to identify issues in DIY electronics or educational experiments.
- Equipped with automatic, regular, and one-shot modes for flexible waveform capture.
- Offers rising or falling edge triggers and negative delay for precise signal observation.
- Includes waveform storage to retain data even after power-off.
- Features a built-in 1Hz/3.3V square wave test signal for calibration.
- Displays key parameters like frequency, pulse width, and peak values digitally.
- Supports secondary development, such as converting to a millivoltmeter.
Key specs include a 1Msps sampling rate, 0-200KHz analog bandwidth, and compatibility with DC 9V power. This kit fits those seeking a compact, user-friendly tool for basic to intermediate signal analysis needs.
