The Passive HD Video Balun Set is designed for transmitting HD video signals from security cameras over twisted pair cables, eliminating the need for lengthy coaxial runs.
In a typical setup, such as monitoring a large warehouse or home perimeter, this balun set extends video feeds reliably, helping to save on installation costs and simplify wiring by using existing Cat5e or Cat6 cables.
- Transmits up to 450m for 720P CVI cameras and 250m for 1080P CVI cameras, ensuring clear signals over distances.
- Requires no external power, making it easy to integrate into existing systems.
- Compatible with HD-CVI, HD-TVI, HD-AHD formats, plus NTSC, PAL, and SECAM standards.
- Features built-in surge protection up to 4KV and ESD protection, safeguarding against electrical interference.
- Offers 60dB crosstalk and noise immunity for stable video transmission.
- Compact design with easy BNC and terminal connections for quick installation.
Light specifications include a frequency response of DC to 60MHz and minimal attenuation of 0.5dB, making it a practical choice for enhancing security camera networks in residential or commercial environments.
