A compact, stainless steel booster pump for reliable water lifting with an 8 m head, designed for submersible use.
Common in domestic boosters, small irrigation, aquariums, solar fountain loops, and compact cooling or circulation systems.
- Submersible design with epoxy-encapsulated stator and PCB for waterproof reliability.
- 8 m head and 17 L/min flow at 30 W; operates on DC12V or DC24V (ranges 7–14V and 5–28V).
- Ceramic (zirconia) shaft option for high wear resistance; stainless steel shaft available to reduce cost.
- No carbon brushes; electronic commutation reduces maintenance and extends life.
- Optional PWM or analog (0–5V) speed control; voltage can be adjusted without changing frame size.
- Shock-absorbing silicone mounting on the bottom plate reduces vibration and noise; position is adjustable.
Voltage: DC12V (7–14V) or DC24V (5–28V); Flow: 17 L/min; Head: 8 m; Power: 30 W. Fully waterproofed with epoxy-encapsulated components.
Fit: Suitable for flat mounting surfaces; bottom plate accepts a silicone damper for easy installation. Amphibious use requires placement below the liquid level when used outdoors.
